1、What is a scissor lift?
Scissor lift is a widely used special equipment for aerial work. It’s a scissor mechanical structure that the lifting platform has a high degree of stability, a comprehensive operating platform, and high load-bearing capacity, so the scope of aerial work is more extensive and suitable for more people to work simultaneously.

2、Lifting capacity of each platform height of the scissor lift
According to CFMG brand scissor lifts as an example:
The weight range of a 19 foot scissor lift is 3527 lbs – 4630 lbs (1600KG ~ 2100KG), the platform load-bearing capacity is 440 lbs – 1102 lbs (200KG ~ 500KG), and the extended platform load-bearing capacity is 249 lbs (113KG).
The 26 foot scissor lift has a weight range of 4894 lbs – 6644 lbs (2220KG ~ 3014KG), a platform load-bearing capacity of 507 lbs – 992 lbs (230KG ~ 450KG), and an extended platform load-bearing capacity of 249 lbs (113KG).
30 ft scissor lift is 7,275 lbs (3,300KG), platform load-bearing capacityis 705 lbs (320KG), extended platform load-bearing capacity is 249 lbs (113KG)
32 foot scissor lift weight is 6463 lbs (2932 kg), platform load-bearing capacity is 705 lbs (320 kg), and extended platform load-bearing capacity is 249 lbs (113 kg).
The 38 foot scissor lift weighs 6,591 lbs (2,990 KG) with a platform load-bearing capacity of 705 lbs (320 KG) and an extended platform load-bearing capacity of 249 lbs (113 KG).
The 40 foot scissor lift weighs 10,802 lbs (4,900 KG) with a platform load-bearing capacity of 804 lbs (365 KG) and an extended platform load-bearing capacity of 308 lbs (140 KG).
The 45 foot scissor lift weighs 10,758 lbs (4,880 KG) with a platform load-bearing capacity of 507 lbs (230 KG) and an extended platform load-bearing capacity of 249 lbs (113 KG).
The weight range for the 52 foot scissor lift is 17636 lbs – 18474 lbs (8000KG ~ 8380KG), with a platform load-bearing capacity of 1499 lbs (680KG) and an extended platform load-bearing capacity of 507 lbs (230KG).
Note: What is extended platform capacity
To expand the working area of the scissor lift, the load capacity of the extended part of the operating platform of the scissor lift becomes the ample platform capacity.

Get An Instant Quotation Now

3、Factors Affecting the Load Capacity of Scissor Lifts

Platform Size: Scissor lift platforms come in various shapes and sizes that impact their load-bearing capacities significantly. Larger platforms provide additional room for materials and personnel while increasing stress on a scissor mechanism due to heavier loads being supported by these lifting surfaces.

Scissor Mechanism Design:
When it comes to scissor mechanism design and construction, design considerations play a pivotal role. Materials chosen, crossbar configuration, and overall structural integrity play vital roles. High-quality materials combined with robust designs will optimize the load-bearing capacities of any lift system.

Hydraulic System: A scissor lift’s hydraulic system drives its vertical movement, directly impacting how effectively and powerfully the lift handles heavy loads. Regular maintenance and proper functioning of all the hydraulic components is critical in upholding the load capacity of any scissor lift.

Power Source:
Scissor lifts can be powered by electric, diesel, or hydraulic systems – each choice affecting capacity – typically, electric charges have lower load capacities than their diesel counterparts; understanding your specific task requirements will enable you to select an appropriate power source with optimal load handling results.

Operating Environment: mes A scissor lift’s load capacity depends heavily on its operating environment, with uneven surfaces, slopes, obstacles, and weather all affecting it. Manufacturers frequently provide load capacity ratings based on specific conditions, so safe and efficient operations must follow these recommendations for safe operations.

4、Why the weight of the scissor lift is so important
The machine’s weight determines the platform capacity, lifting capacity, and working height. More specifically, it affects the following aspects:
Equipment transportation: The lighter the weight of the scissor lift, the easier it is to move. For example, a truck can hold up to 22 lightweight hybrid lifts, about 8 more than when carrying a conventional charge.
Load Capacity and Weight Limit: Larger, heavier scissor-type aerial work platforms (e.g., rough terrain scissor-type aerial work platforms) tend to have higher platform capacity and weight limits.
The weight of the lift makes it more convenient for users to choose the right product for them.

5、What factors should be considered when choosing a scissor lift
Load capacity: The first step is to determine the maximum load capacity required to meet the needs of use. According to the number and weight of operators, ensure that they can safely and efficiently complete the lifting task.
Lifting height: Select the appropriate height according to the working environment and demand. Considering the limitation of indoor space and working size, choose the scissor raise that meets the requirements.
Size and platform area: The size and platform area of the scissor lift should be adapted to the required working environment and operating space. Select a scissor lift with a large enough platform area and appropriate size to provide a safe and stable working environment.
Power mode: Scissor lifts can use electric or hydraulic power, and the appropriate power mode is selected according to the actual situation. Considering factors such as cost of use, energy efficiency, and noise, choose the power method that suits your needs.
Safety performance and standards: Ensure the scissor lift complies with relevant safety standards and regulatory requirements. Check whether it has safety equipment such as fall protection, overload protection, emergency stop button, etc., and whether it meets the corresponding certification and quality management system requirements.
Cost and cost-effectiveness: Finally, you must consider the price, performance, and quality to choose a scissor lift with good cost-effectiveness. Not only should we focus on the reasonableness of the price, but also ensure the quality and reliability of the product to meet the actual needs and enhance work efficiency.
6、About CFMG
CFMG is the largest scissor lift manufacturer brand in north China, with 15 years of manufacturing and sales experience, factory direct sales, annual sales of more than a thousand units, more than a hundred R & D team, one-on-one after-sales service, meet all of your scissor lift for lifts.
